Eclipse XP General Description

The ECLIPSE XP™ electric emergency shutdown system uses a unique and modern approach to instantly stop the flow of chlorine or SO2 at the tank valve. In contrast to traditional pneumatic systems, the ECLIPSE XP electric actuators operate off of a 12 VDC battery located in the controller that is continuously charged via line voltage.

Should the plant ever lose AC power to the controller, the battery has enough power to safely operate the system for up to 3 days and multiple valve closures. Because the system can detect a spike in electrical current to the motor, the actuator is able to detect the torque that is generated as the valve begins to engage the valve seat. This unique and patented feature allows the operators to know that not only did they activate their system, but that the valve is actually closed. No other actuator on the market is able to make this claim.

Features:

• All electric/battery powered operation.
• Torque Sense Technology knows when valve is closed.
• No Pneumatics: Maintenance free /very low power use.
• Simple installation, no separate storage kiosk required.
• Closes valve in 1 second.
• Up to 3 days of built-in battery backup.
• Independent test buttons for each cylinder.
• Shutdown via gas detectors, panic buttons or PLC.
• 3 year warranty.
